1. The PE PVC double wall corrugated pipe production line is configured single screw extruder and grooved feed barrel, which ensures extruding in high efficiency.
2. Corrugated forming system with strong cooling ability ensures constant production with high speed.
3. The mould surface is nitrided and polished. A wall thickness-regulating device is equipped in die lip to be suitable for production of different raw materials and ring resistance materials.
4. Advanced on line socketing function lowers the investment and increases the efficiency.
5. The PE PVC double wall corrugated pipe production line adopts SIEMENS PLC computer controlled system with touched screen man-machine interface, which guarantee automatic and reliable operator.
| Model | SBW×1500 | SBW×1000 | SBW×500 | SBW×250 | SBW×160 | SBW×90 |
| Structure Form | Vertical | Vertical | Horizontal | Horizontal | Horizontal | Horizontal |
| Applicable Raw Materials | HDPE | HDPE | HDPE | HDPE | HDPE | HDPE |
| Pipe Diameter Range | 400-1500 | 250-1000 | 160-500 | 90-250 | 75-160 | 40-90 |
| Max Extrusion Output | 1200 | 850 | 600 | 350 | 200 | 100 |
| Expansion Mode | Belling-on-line,double-wall socket joint | Belling-on-line,double-wall socket joint | Belling-on-line,double-wall socket joint |
This PE PVC double wall corrugated pipe production line is used to produce double wall corrugated pipe with PVC or PE as materials. This kind of pipe has unique structure and many advantages such as: light mass, impact resistance, corrosion endurance, cold and heat resistance. So, this kind pipe is widely used in the fields of communication, paving of wire and cable, agricultural irrigation, water supply and drainage in cities, geographic deep irrigation and feed water in architecture, etc.
PE/PVC Double Wall corrugated pipe production line
Pipe diameter:40-1500mm
Useful material:PE/PVC
Produce speed:0-8m/min
