Principle of plastic pulverizer (PE pulverizer, pvc pulverizer, high speed plastic pulverizer)
The material feed into the machine at a regular velocity from the station disc, then with the force of centrifuge force formed by feeding leaf and the rotation of moving disc, by the function of compacting and shearing of the two disc, the material is thrown to the outsides girt gear, and the fine material discharge from the machine.
|
Model |
Motor power(KW) |
Fans power (KW) |
Vibration power(KW) | Feed power(KW) | Output (Kg/h) |
Dimension (mm) |
Weight (kg) |
| MF-250 | 7.5 | 1.5 | 1.1 | 0.55 | 50-120 | 1500×800×2800 | 1100 |
| MF-350 | 22 | 3 | 1.1 | 0.55 | 120-200 | 1700×1500×3700 | 1200 |
| MF-450 | 37 | 4 | 1.5 | 0.55 | 180-300 | 1800×1600×3800 | 1600 |
| MF-550 | 45 | 5.5 | 1.5 | 0.75 | 260-400 | 1900×1700×3900 | 2200 |
| MF -650 | 55 | 5.5 | 2.2 | 0.75 | 430-550 | 2000×1800×4000 | 2700 |
| MF-800 | 75 | 7.5 | 2.2 | 1.1 | 550-680 | 2300×1900×4100 | 3500 |
Feature of plastic pulverizer
1. Small sectional area, and the grinding tooth-plate is vertical installed, so the material can pass through to the grind area at highest speed, no super-grind, the temperature won't rise.
2. High grind line-speed, compact in construction, minimum amount of the floor space.
3. Control the particle size by adjusting the gap of the tooth-plate.
4. High quality, used in neg. Press operation process and normal press operation process.
5. The machine running balance, large capacity, easy to operating and fixing.
PVC Pulverizer Widely used in rubber and plastic industry. It can not only grind PVC, but also grind PE, PS, PA, PC and other plastics.
Quick Detail:
1. spot goods
2. good sell service
